OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 00-880706-01 Cover, Collimator 1
2 00-877031-01 Clip, Collimator Cover 1
3 12-225160-12 Screw, SEMS, Spring, Pan, Torx, 10-32, 3/4, SZC 2
4 00-879575-01 Collimator, Secondary, 9-Inch, 3 Pot 1
5 12-225108-06 Screw, NA, Socket, Hex, 10-32, 3/4, SZC 4
6 00-880430-02 Assembly, Collimator, Base Unit 1
7 12-211114-14 Screw, NA, Socket, Hex, 1/4-20, 7/8, SZC, 8 6
8 00-876567-02 Bumper, X-Ray Mount 1
9 12-225106-06 Screw, SEMS, Spring, Pan, Torx, 6-32, 3/8, SZC 6
10 22-678482-00 Ring, Retaining, Internal, Spl, 2.312 SST 1
11 00-880838-01 Collimator, Primary 9-Inch 1
12 00-880855-01 Spacer, Foam, primary, Collimator 1
13 00-877286-01 Cover, X-Ray Tube 1
14 00-881519-01 Assembly, X-Ray Tube, External Mount 1
15 00-901753-01 Assembly, Thermal Switch (not exploded for clarity) 1
16 12-225160-10 Screw, NA, Socket, Hex, 10-32, 5/8, SZC 2
17 00-875607-01 Cover, High Voltage Cable 1
18 00-901141-01 Cable, High Voltage Control, Standard (not exploded or shown for clarity) 1
19 00-901141-03 Cable, High Voltage Control, Super C & Cardiac (not exploded or shown for clarity) 1
20 00-877320-02 Assembly, Skin Spacer (not shown) 1
21 00-881499-01 Assembly, Temp Sensor, X-Ray (not exploded or shown for clarity) 1
Figure 3. X-Ray Tube, Collimator Parts List
