OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 00-879984-01 Bracket, Inductor 1
2 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 8-32, 3/8, SZC 8
3 00-879800-01 Assembly, Series Tuning Indicator 1
4 14-121114-00 Washer, Plain, 1/4, SST, MS15795-810 1
5 14-211114-00 Washer, Lock-HLCL-Spring, 1/4, SST, MS35338 1
6 12-311114-26 Screw, NA, Socket, Hex, 1/4-20, 1-3/4, SZC 1
7 00-879783-01 Chassis Component 1
8 13-311108-00 Nut, Hex-Lock-External-T, 8-32, SST, NA, A=.344 3
9 12-225106-08 Screw, SEMS, Spring, Pan, Torx, 6-32, 1/2, SZC 10
10 00-879784-01 Bracket, Component Clamp 1
11 41-718504-00 Capacitor, Polypropylene,2uF, 600 V, 10%, Terminals 4
12 00-879785-01 Cover, Component, Clamp 1
13 22-012002-00 Clamp, Cable/Wire, 5/8D, .50W, Nylon 1
14 00-901177-01 Power Supply, 24VDC 1
15 00-879674-01 Assembly, Power Supply, Multi-output 1
16 22-012000-00 Clamp, Cable/Wire, 3/4D, .50W, Nylon 1
17 00-879970-01 Assembly, Fan, Power Supply 1
18 12-225106-22 Screw, SEMS, Spring, Pan, Torx, 6-32, 1-1/4, SZC 2
19 22-1200012-00 Clamp, Cable Ribbon, Qik-Lok, .73x3.00, Nylon 2
Figure 11. Power Supply Parts List
