GE OEC 9800 C-Arm - Battery and Power Panel Section; Battery, Power Panel Parts List

16
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 8-32, 3/8, SZC 2
2 00-879870-01 Assembly, Stator Capacitor/Transformer 1
3 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 8-32, 3/8, SZC 4
4 00-879124-01 Assembly, Power Panel 1
5 00-880519-01 Gasket, Lemo Connector 1
6 12-225109-10 Screw, SEMS, Spring, Pan, Torx, 8-32, 5/8, SZC 4
7 00-879325-01 PCB, Power/Motor Relay 1
8 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 8-32, 3/8, SZC 1
9 00-880406-02 Assembly, Capacitor/Power Module 1
10 00-900589-01 Battery Pack 1
11 00-875583-01 Retainer, Battery 2
Figure 5. Battery, Power Panel Parts List
