GE Optima XR220amx User Manual

Chapter 13: Digital Detector
Optima XR220amx X-Ray System 54400222-1EN Rev 1 DRAFT 11092010 13-5
Operator Manual © 2010 General Electric Company. All rights reserved.
Figure 13-4 Detector Docking Connector
Table 13-4 Detector Docking Connector
Figure 13-5 Detector Top
Table 13-5 Detector Top
Item Description
1 Detector Docking Connector
Item Description
1 Pushbutton: Push to toggle between normal mode and sleep mode.
2 Indicator Lights
3 Detector ID Insert - See Chapter 14: Set Preferences-Adding A New Detector Identified By Color
and Shape
4Battery
