GE P643 User Manual

Appendix A - Ordering Options
P64x
V
ariants Order Numbe
r
P645 Transformer Protection P645 **
V
x Aux Rating :
24 - 54Vdc 7
48 - 125Vdc (40 - 100Vac) 8
110 - 250 Vdc (100 - 240 Vac) 9
In/Vn Rating :
HV-LV In = 1A/5A, Vn = (100/120V) (18CT/1VT) 1
HV-LV In = 1A/5A, Vn = (100/120V) (18CT/4VT) 2
IEC 61850-9-2LE Sampled Analogue Values Ethernet board *
C
* Only available with '12'/'20' Software on 80TE/40TE models
Hardware Options :
Standard : no options 1
IRIG-B (Modulated) only 2
Fibre Optic Converter only 3
IRIG-B (Modulated) & Fibre Optic Converter 4
Ethernet (100Mbit/s) 6
Second Rear Comms Port (Courier EIA232/EIA485/k-bus) 7
Second Rear Comms Port + IRIG-B (modulated) (Courier EIA232/EIA485/k-bus) 8
Ethernet (100Mbit/s) plus IRIG-B (Modulated)
A
Ethernet (100Mbit/s) plus IRIG-B (Un-modulated) B
IRIG-B (Un-modulated) C
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B
K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B M
Redundant Ethernet PRP/HSR*, 2 fibre ports + Modulated IRIG-B
N
Redundant Ethernet PRP/HSR*, 2 fibre ports + Unmodulated IRIG-B
P
* HSR – contact Alstom for details
Product Specific Options :
Size 12 (60TE) case, 16 optos + 16 relays
A
Size 12 (60TE) case, 16 optos + 16 relays + RTD B
Size 12 (60TE) case, 16 optos + 16 relays + CLIO (mA I/O) C
Size 12 (60TE) case, 24 optos + 16 relays D
Size 12 (60TE) case, 16 optos + 24 relays E
Size 16 (80TE) case, 24 optos + 24 relays or Size 8 (40TE) 8 optos 8 relays Mounting Opt R
F
Size 16 (80TE) case, 24 optos + 24 relays + RTD G
Size 16 (80TE) case, 24 optos + 24 relays + CLIO (mA I/O) H
Size 16 (80TE) case, 24 optos + 24 relays + RTD + CLIO (mA I/O) J
Size 12 (60TE) case, 16 optos + 20 relays (including 4 high break)
K
Size 16 (80TE) case, 24 optos + 20 relays (including 4 high break) L
Size 16 (80TE) case, 24 optos + 20 relays (including 4 high break) + RTD M
Size 16 (80TE) case, 24 optos + 20 relays (including 4 high break) + CLIO (mA I/O) N
Size 16 (80TE) case, 24 optos + 20 relays (including 4 high break) + RTD + CLIO (mA I/O) P
Size 16 (80TE) case, 16 optos + 24 relays (including 8 high break) Q
Size 16 (80TE) case, 16 optos + 24 relays (including 8 high break) + RTD R
Size 16 (80TE) case, 16 optos + 24 relays (including 8 high break) + CLIO (mA I/O) S
Size 16 (80TE) case, 16 optos + 24 relays (including 8 high break) + RTD + CLIO (mA I/O) T
Size 16 (80TE) case, 40 optos + 24 relays U
Size 16 (80TE) case, 40 optos + 16 relays + RTD
V
Size 16 (80TE) case, 40 optos + 16 relays + CLIO (mA I/O) W
Size 16 (80TE) case, 40 optos + 8 relays + RTD + CLIO (mA I/O)
X
Size 16 (80TE) case, 40 optos + 20 relays (including 4 High Break) Y
Size 16 (80TE) case, 40 optos + 12 relays (including 4 High Break) + RTD Z
Size 16 (80TE) case, 40 optos + 12 relays (including 4 High Break) + CLIO (mA I/O) 1
Protocol Options :
K-Bus/Courier 1
Modbus 2
IEC60870-5-103 3
DNP3.0 4
IEC 61850 over Ethernet and Courier via rear K-Bus/RS485 6
DNP3.0 over Ethernet and Courier via rear K-Bus/RS485 8
Mounting Options :
Flush/Panel Mounting with Harsh Environment Coating M
Rack Mounting with Harsh Environment Coating (80TE Only) N
40TE Case (9-2LE models only) Flush/Panel Mount with Harsh Environmental Coating R
Language Options :
English, French, German, Spanish 0
English, French, German, Russian 5
Chinese, English or French via HMI, with English or French only via Communications port C
Software Version Options :
Unless specified the latest version will be delivered **
Settings Files Options :
Default 0
Customer Specific
A
Design Suffix :
Factory determined
A3
P64x-TM-EN-1.3
