GE QuickPanel+ IC755CxS06RDx

Overview
For public disclosure
GFK-2847W 13
1.1.1.4 IC755CxS12CDx Specifications
Item
Specification
Processor
Freescale i.MX535 (1 GHz ARM Cortex A8)
Memory
RAM
DDR3 SDRAM 1 GB
ROM
SLC NAND 512 MB
SRAM
512 KB (with battery backup)
Operating System
Microsoft Windows Embedded Compact 7
Display
Type
12.1" Standard TFT LCD
Resolution
800(W) x 600(H) pixels SVGA
Color
65,536
Brightness
450 cd/m
2
Backlight
LED
Touchscreen
Touch Panel Type
Projected capacitive
Multi-touch
Two-point
Communications
Ethernet Port
2x 10/100Base-T (RJ-45)
1x 10/100Base-T (RJ-45) for IC755CxS12CDA
Serial Port
1x RS-232 UART port
1x RS-232/485 port (2x 5-pin connector) (1x
10-pin connector for IC755CxS12CDA)
USB, Host
2x USB 2.0 (Type-A) max power (5 V at 0.5 A)
USB, Device
1x USB 2.0 (mini Type-B)
Storage
1x SD/SDHC card slot
Audio
1x Line Out (Stereo) (3.5 mm jack)
Noise Immunity
Noise voltage
1500 V p-p
Pulse duration
1µs
Rise time
1ns
Input power
Rated Voltage
12/24 V dc ±20% (3-pin connector)
Power Consumption
30 W maximum, 2.5 / 1.25 A
Frame Ground (FG)
Frame GND is connected internally to Signal GND
Dimensions (L×W×D)
314 × 248 × 65 mm (12.36 × 9.76 × 2.56 in)
Weight
3 kg (6.61 lbs)
Mounting Options
Panel Cutout Dimensions
302 × 228 mm (11.89 × 8.98 in)
VESA Mount
100 x 100 mm (3.94 x 3.94 in)
