QuickPanel⁺ Operator Interface User
Manual
SD Card
T ouchscreen
LCD
St a t us
I ndica t or
L E D
L A N2 L A N1 USB
MICRO C O M2 COM1
L I N E
I npu t
Hos t
P or t s
U SB
O U T
P ower
IC755CxS15CDx Hardware Features
Note Refer to the section IC755CxS15CDx Specifications for drawing dimensions.
