GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–51
REV 24
OPERATOR CSL ASSY FOR PAL SHORT MODEL
P9515DA, DB, DC, DD, DE, DF, DG, DH, DJ, DK, DL, HB, DN, DP, HC, DQ,
DR, HD, 2159905 (P9515DS), 2159907 (P9515DT), 2159909 (P9515HE),
MATERIAL LIST (2/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
18 TIE WRAP U0201AC 6 FOR P9515DA, DB, DC,DD, DE, DF, DG, DH
4 FOR P9515DJ, DK, DL, HB, DN, DP, HC, DQ,
DR, HD, DS, DT, HE
19 CLAMP U0012AC 5 CKN–10
20 CLAMP U0013AC 2 FOR P9515DA, DB, DC, DD, DE, DF, DG, DH
6 FOR P9515DJ, DK, DL, HB, DN, DP, HC, DQ,
DR, HD, DS, DT, HE
21 PWR CORD HOOK P9500EX 1
22 GRIPPER P9510EG 2
23 FRONT COVER P9514BH 1 FOR P9515DA, DB, DC, DD, DE, DG, DH
FOR P9515DJ, DK, HB, DN, DP, HC
FOR P9515DQ, DR, HD, DS, DT, HE
P9514HD 1 FOR P9515DL
24 REAR COVER P9514BJ 1 FOR P9515DA, DB, DC, DD, DE, DF, DG, DH,
DJ, DK, HB, DN, DP, HC, DQ, DR, HD, DS,
DT, HE
P9514HE 1 FOR P9515DL
25 COVER PLATE P9514BL 1
26 FRONT PANEL ASSY P9514JD 1
27 KB BOTTOM COVER P9514BN 1
28 UPPER PANEL ASSY P9514JG 1 FOR P9515DA, DB, DC, DD, DE, DF, DG, DH,
DJ, DK, DL, HB, DN, DP, HC, DQ, DR, HD
2164140 1 FOR P9515DS, DT, HE
29 REAR BOX P9514BQ 1
30 TEL LABEL 2156773 1
33 NAME PLATE P9140EU 1 FOR P9515DA, DB, DC, DD, DE, DF, DG, DH,
DJ, DK, HB, DN, DP, HC, DQ, DR, HD, DS,
DT, HE
35 MAGNET U0426AE 24 [cm]
36 CAP P9123PC 8
37 CAUTION LABEL P9514GK 1 FOR P9515DL
P9514GV 1 FOR P9515HB, HC, HD, HE
41 KB PANEL P9514BB 1
42 BASE R P9514BC 1 FOR P9515DA, DB, DC, DD, DE, DF, DG, DH
P9514HS 1 FOR P9515DJ, DK, DL, HB, DN, DP, HC, DQ,
DR, HD, DS, DT, HE
