GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–53
REV 25
OPERATOR CSL ASSY FOR PAL SHORT MODEL
P9515DA, DB, DC, DD, DE, DF, DG, DH, DJ, DK, DL, HB, DN, DP, HC, DQ,
DR, HD, 2159905 (P9515DS), 2159907 (P9515DT), 2159909 (P9515HE),
MATERIAL LIST (4/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
59 CLAMP U0006AC 1
60 SILICON TUBE U0489BA 110 [CM]
71 CASE XFMR P9514DB 1 FOR P9515DA, DB, DC, DD, DF, DG, DH
CASE XFMR 2 P9514DN 1 FOR P9515DJ, DK, DL, HB, DE, DN, DP, HC,
DQ, DR, HD, DS, DT, HE
72 CASE XFMR REAR P9514HG 1 FOR P9515DA, DB, DC, DD, DF, DG, DH
CASE XFMR REAR 2 220V P9514DQ 1 FOR P9515DJ, DK, DL, HB, DE, DN, DP, HC,
DQ, DR, HD, DS, DT, HE
73 CASE PS TOP P9514DE 1
74 CASE PS REAR P9514DF 1
75 CASE PS FRONT P9514DG 1
76 CASE PS P9514DH 1
77 PS SPRT 1 P9514DJ 1 Rev. 1
78 PS SPRT 2 P9514DK 1
79 PS SPRT 3 P9514DL 1 Rev. 1
80 PS SPRT 4 P9514DM 1 Rev. 1
Note
The PS SPRT 1, PS SPRT 3, and the PS SPRT 4 (Items 77, 79, and 80) are modified with the change
of the SW Regulators. Each PS SPRT modified can be mounted on both old and new SW Regulators,
respectively.
81 CORD STOPPER U0549AC 1
83 NAME PLATE U0022BN 10 FOR P9515DA, DB, DC, DD, DE, DF, DG, DH,
DJ, DK, DL, DN, DP, DQ, DR, DS, DT, HE
9 FOR P9515HB, HC, HD
101 SCREW P9503LH 2
102 SPACER P9506LZ 1
103 STOPPER BLOCK P9510DL 2
104 BEARING SPRT P9514CB 4
105 STOPPER P9514CD 1
