RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–57
REV 25
OPERATOR CSL ASSY FOR PAL SHORT MODEL
P9515DA, DB, DC, DD, DE, DF, DG, DH, DJ, DK, DL, HB, DN, DP, HC, DQ,
DR, HD, 2159905 (P9515DS), 2159907 (P9515DT), 2159909 (P9515HE),
MATERIAL LIST (8/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
254 MST–E ASSY P9514XG 1 FOR P9515DA, DB, DC, DD
MST–C2 ASSY P9514YH 1 FOR P9515DE, DF, DG, DH
MST–C3 ASSY P9514ZR 1 FOR P9515DJ, DK, DL
MST–E3 ASSY P9514ZT 1 FOR P9515HB
MST–C4 ASSY P9514ZX 1 FOR P9515DN, DP
MST–E4 ASSY P9514ZZ 1 FOR P9515HC
P9514ZD MST–C5 2113954–4 1 FOR P9515DQ, DR
P9514ZN MST–C6 ASSY 2159934 1 FOR P9515DS, DT
P9514ZC MST–E5 2113953–5 1 FOR P9515HD
P9514ZM MST–E6 ASSY 2159933 1 FOR P9515HE
255 SCC–P ASSY P9514XK 1
256 FM–P ASSY P9514XM 1 FOR P9515DA, DB, DC, DD
FM–PA ASSY P9514YM 1 FOR P9515DE, DF, DG, DH, DJ, DK, DL, HB,
DN, DP, HC, DQ, DR, HD, DS, DT, HE
257 VDO–P ASSY P9514XP 1 FOR P9515DA, DB, DC, DD
VDO–P2 ASSY P9514ZP 1 FOR P9515DE, DF, DG, DH, DJ, DK, DL, DN,
DP, DQ, DR, DS, DT
VDO–PA ASSY P9514YP 1 FOR P9515HB, HC, HD, HE
258 MOTHER B’d ASSY P9514WT 1
259 CONN B’d ASSY P9514WV 1
260 HV ASSY P9514WX 1
281 XFMR ASSY P9514JL 1
282 SW REGULATOR U0219EE 1 RT–3–5FF
283 SW REGULATOR U0231EE 1 K100AU–5
SW REGULATOR 2222324 1 R100U–5, including PS SPRT4 (
P9514DM Rev.1)
284 SW REGULATOR U0261EE 1 K50AU–12
SW REGULATOR 2222325 1 R50U–12, including PS SPRT3 (P9514DL Rev.1)
285 SW REGULATOR U0262EE 1 K10AU–5
SW REGULATOR 2222326 1 R15U–5, including PS SPRT1 (
P9514DJ Rev.1)
Note
Three types of the SW Regulators (Items 283, 284, and 285) change to new ones because of the
discontinuance of parts. You can replace old SW Regulator with new one using modified PS SPRT
supplied with each new SW Regulator.
