GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–93
REV 25
OPERATOR CSL ASSY FOR 220V NTSC SHORT MODEL
2132043
MATERIAL LIST (8/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
251 RFL–A ASSY P9514XA 1
252 RRS–A ASSY P9514XC 1
253 P9514YC TRC–J5 2113950 1
254 P9514ZE MST–J5 2113955–5 1
255 SCC–N ASSY P9514WK 1
256 FM–NA ASSY P9514XN 1
257 VDO–N2 ASSY P9514YQ 1
258 MOTHER B’d ASSY P9514WT 1
259 CONN B’d ASSY P9514WV 1
260 HV ASSY P9514WX 1
281 XFMR ASSY P9514JL 1
282 SW REGULATOR U0219EE 1 RT–3–5FF
283 SW REGULATOR U0231EE 1 K100AU–5
SW REGULATOR 2222324 1 R100U–5, including PS SPRT4 (
P9514DM Rev.1)
284 SW REGULATOR U0261EE 1 K50AU–12
SW REGULATOR 2222325 1 R50U–12, including PS SPRT3 (
P9514DL Rev.1)
285 SW REGULATOR U0262EE 1 K10AU–5
SW REGULATOR 2222326 1 R15U–5, including PS SPRT1 (
P9514DJ Rev.1)
Note
Three types of the SW Regulators (Items 283, 284, and 285) change to new ones because of the
discontinuance of parts. You can replace old SW Regulator with new one using modified PS SPRT
supplied with each new SW Regulator.
286 CIRCUIT PROTECTOR U0025EK 2 1A
288 CIRCUIT PROTECTOR U0043EK 3 5A
290 TERMINAL U0002FP 2 6
291 TERMINAL U0003FP 1 12
292 TERMINAL U0108FP 1 3
293 NAME PLATE Z9814PX 1
294 POWER SW ASSY P9515XZ 1
295 TROIDAL CORE U0012MC 5 TR–28–16–13
296 DISCON PLATE P9500DZ 1
297 NAME PLATE Z9814QX 1 G
298 NAME PLATE Z9814QY 1 D+5V
299 NAME PLATE Z9814QZ 1 D+12V
