GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–100
REV 25
OPERATOR CSL ASSY FOR 100V NTSC SHORT MODEL
P9515AA, AB, AC, AD, AJ, AK, AL, AM, AS, AT, AW, AX,
2112635, 2112637
MATERIAL LIST (3/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
48 BOLT P9514BR 8
50 FRONT PLATE P9514BV 1
51 FRONT SIDE BRKT P9514BW 2
52 REAR SIDE BRKT P9514BX 2
53 ACCESSORY BOX P9514FC 1
54 FAN ASSY P9514JJ 1
55 CASTER U0102AE 2 FOR P9515AA, AB, AC, AD
U0134AE 2 FOR P9515AJ, AK, AL, AM, AS, AT, AW, AX,
2112635, 2112637
56 CASTER U0130AE 2 FOR P9515AA, AB, AC, AD
U0137AE 2 FOR P9515AJ, AK, AL, AM, AS, AT, AW, AX,
2112635, 2112637
57 RUBBER SHEET 1 P9514FP 1
58 RUBBER SHEET 2 P9514FQ 1
59 CLAMP U0006AC 1
60 SILICON TUBE U0489BA 110 [CM]
71 CASE XFMR P9514DB 1 FOR P9515AA, AB, AC, AD
P9514DN 1 FOR P9515AJ, AK, AL, AM, AS, AT, AW, AX,
2112635, 2112637
72 CASE XFMR REAR P9514DC 1 FOR P9515AA, AB, AC, AD
P9514DP 1 FOR P9515AJ, AK, AL, AM, AS, AT, AW, AX,
2112635, 2112637
73 CASE PS TOP P9514DE 1
74 CASE PS REAR P9514DF 1
75 CASE PS FRONT P9514DG 1
76 CASE PS P9514DH 1
77 PS SPRT 1 P9514DJ 1 Rev. 1
78 PS SPRT 2 P9514DK 1
79 PS SPRT 3 P9514DL 1 Rev. 1
80 PS SPRT 4 P9514DM 1 Rev. 1
Note
The PS SPRT 1, PS SPRT 3, and the PS SPRT 4 (Items 77, 79, and 80) are modified with the change
of the SW Regulators. Each PS SPRT modified can be mounted on both old and new SW Regulators,
respectively.
