GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–117
REV 25
OPERATOR CSL ASSY FOR 100V NTSC TALL MODEL
P9515AE, AF, AG, AH, AN, AP, AQ, AR, AU, AV, AY, AZ,
2112640, 2112642
MATERIAL LIST (8/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
256 FM–N ASSY P9514WM 1 FOR P9515AE, AF, AG, AH
FM–NA ASSY P9514XN 1 FOR P9515AN, AP, AQ, AR, AU, AV, AY, AZ,
2112640, 2112642
257 VDO–N ASSY P9514WP 1 FOR P9515AE, AF, AG, AH
VDO–N2 ASSY P9514YQ 1 FOR P9515AN, AP, AQ, AR, AU, AV, AY, AZ,
2112640, 2112642
258 MOTHER B’d ASSY P9514WT 1
259 CONN B’d ASSY P9514WV 1
260 HV ASSY P9514WX 1
281 XFMR ASSY P9514JL 1
282 SW REGULATOR U0219EE 1 RT–3–5FF
283 SW REGULATOR U0231EE 1 K100AU–5
SW REGULATOR 2222324 1 R100U–5, including PS SPRT4 (
P9514DM Rev.1)
284 SW REGULATOR U0261EE 1 K50AU–12
SW REGULATOR 2222325 1 R50U–12, including PS SPRT3 (P9514DL Rev.1)
285 SW REGULATOR U0262EE 1 K10AU–5
SW REGULATOR 2222326 1 R15U–5, including PS SPRT1 (P9514DJ Rev.1)
Note
Three types of the SW Regulators (Items 283, 284, and 285) change to new ones because of the
discontinuance of parts. You can replace old SW Regulator with new one using modified PS SPRT
supplied with each new SW Regulator.
286 CIRCUIT PROTECTOR U0025EK 2 1A
288 CIRCUIT PROTECTOR U0040EK 2 10A
289 CIRCUIT PROTECTOR U0043EK 1 5A
290 TERMINAL U0002FP 2 6
291 TERMINAL U0003FP 1 12
