SecoGear – Installation, Operation and Maintenance Manual 32 of 56
Figure 4-20: Main Bus Connection – Rear View
Table 4-7: Main Bus Sizes
Table 4-8: Riser/Runback Bus Size
CURRENT MATERIAL PIECES SIZE
1200 A / 2000 A Copper 1
.3937 in x 5.9055 in (10 mm x 150 mm)
3000 A Copper 2
.3937 in x 5.9055 in (10 mm x 150 mm)
CURRENT MATERIAL PIECES SIZE
1200 A Copper 1
.3937 in x 3.1496 in (10 mm x 80 mm)
2000 A Copper 2
.3937 in x 3.1496 in (10 mm x 80 mm)
