SecoGear – Installation, Operation and Maintenance Manual 33 of 56
Figure 4-21: Main Bus Connection – Plan (Top) View
Figure 4-22: Main Bus Connection – Through Joint
Figure 4-23: Main Bus Connection – Start or End Joint
Through Joint
(Figure 4-14)
Start or End Joint
(Figure 4-15)
Boot
Boot
Riser
Splice Plates
Splice Plates
Main Bus
Main Bus
Riser
