OPM_SGS_USM_10K_40K_0US_V010.doc 19/88 Operating Manual
SG Series
10, 20, 30 & 40 kVA
4.2 LAYOUT SG Series 30 AND 40 KVA
SGT5000_030-040_UPS_GE_02
FIG. 4.2-1 SG SERIES GENERAL VIEW
SGT5000_030-040_UPS_GE_03
Q1
Q2
ON
OFF
OFF
ON
Fig. 4.2-2 SG Series general view with open doors
Fig. 4.2-3 Manual operated switches
Fig. 4.2-4 Control Panel
P4 Customer Interface Board
Q1
UPS output switch
Q2
Manual Bypass switch
SNMP
SNMP Card (option)
XA
Terminals for 24VDC Auxiliary Power Supply connection
SGT5000_100-150_Customer interface_03
SNMP
1
2
3
4
1
2
3
4
XA
P4
XB
Fig. 4.2-5 Connectivity Rack
XB
Terminals for EPO (Emergency Power Off) connection
