OPM_SGS_USM_10K_40K_0US_V010.doc 40/88 Operating Manual
SG Series
10, 20, 30 & 40 kVA
Code Message Meaning
4535
BYPASS
LOCKED
Bypass is not available.
Contactor K6
and
K8
are open,
SSM
deactivated.
4536
BYPASS
FREE
Bypass
is enabled.
Contactor K6 is closed.
4561
TOTAL
OFF
Push-button “total off” on the UPS Control Panel has been
pressed, with the output circuit switch Q1 closed.
4562
DETOUR
ON
The auxiliary contact indicates that Manual Bypass Q2 was
closed.
4564
DETOUR
OFF
The auxiliary contact indicates that
Manual Bypass Q2
was
opened.
4567
COMMAND
LOAD ON UTILITY
The control unit received a command to transfer the Load on
Utility.
4568
COMMAND
LOAD ON INVERTER
The control unit received a command to transfer the Load on
Inverter.
4572
NO MORE
OVERLOAD
End of the overload condition detected with alarm 4570.
4580
INVERTER AND
UTILITY
SYNCHRONIZED
The voltages of Inverter and Utility Bypass are synchronized.
4582
COMMAND
NOT TO
SYNCHRONIZE
Command not to synchronize with Utility.
4583
COMMAND TO
SYNCHRONIZE
Command to synchronize with Utility.
4602
Q1
OPEN
The auxiliary contact indicates that the output switch Q1 was
opened.
4603
Q1
CLOSED
The auxiliary contact indicates that the output switch Q1 was
closed.
4699
BATTERY TEST
IMPOSSIBLE
Automatic Battery Test is not possible due to:
• No Utility Rectifier or Bypass.
• Battery not fully charged.
• Load is below 10% or above 80%.
Test is postponed for 1 week.
4763
REMOTE CONTROL
ON
Inverter can be started or shutdown by remote control.
Commands source can be chosen depending on the value of
parameter (Service only):
0 = Only local panel.
1 = Only serial port on CI.
2 = Both.
4764
REMOTE CONTROL
OFF
Inverter
cannot be started or shutdown by remote control.
Commands source can be chosen depending on the value of
parameter (Service only):
0 = Only local panel.
1 = Only serial port on CI.
2 = Both.
