Scanning
Vscan Air – User Manual 5-9
Direction GP092020-1EN Rev 18
Image crop indicator (continued)
NOTE: When the screen is rotated from portrait to landscape, depth
remains unchanged, refer Figure 5-5.
Figure 5-5. Image crop indicator (landscape mode)
If it is important to visualize the entire width, it is possible to do
one of the below:
1. Rotate the display device to visualize the image in
landscape orientation.
2. If portrait mode is preferred:
• The depth can be increased until the whole width is
displayed, and image crop indicators no longer appear.
• Zoom and pan to visualize the edge of the image on the
desired side.
a. Curved array (deep scanning) transducer
b. Linear array (shallow scanning) transducer
