6 | Compressor assembly
7 | Electrical connection
7.1 Informationforcontactorandmotorcontactorselection
Allprotectiondevicesandswitchingormonitoringunitsmustbettedinaccordancewiththelocal
safetyregulationsandestablishedspecications(e.g.VDE)aswellaswiththemanufacturer’sinfor-
mation. Motorprotectionswitchesarerequired! Motor contactors, feed lines, fuses and motor
protection switches must be rated on the basis of the maximum working current (see name plate).
For motor protection use a current-dependent and time-delayed overload protection device for moni-
toring all three phases. Set the overload protection device so that it must be actuated within 2 hours,
if there is 1.2 times the max. working current.
INFO
Connect the compressor motor in accordance with the circuit diagram
(see inside of terminal box).
Use suitable cable entry point of the correct protection type (see
name plate) for routing cables into the terminal box. Insert the strain
relieves and prevent chafe marks on the cables.
Comparethevoltageandfrequencyvalueswiththedataforthe
mains power supply.
Onlyconnectthemotorifthesevaluesarethesame.
DANGER Riskofelectricshock!Highvoltage!
Onlycarryoutworkwhentheelectricalsystemisdisconnected
fromthepowersupply!
7 Electricalconnection
ATTENTION Whenattachingaccessorieswithanelectricalcable,aminimum
bendingradiusof3xthecablediametermustbemaintainedfor
layingthecable.
6.9Suctionpipelterandlterdrier
For systems with long pipes and higher degree of contamination, a lter on the suction-side is
recommended.Thelterhastobebereneweddependingonthedegreeofcontamination(reduced
pressure loss).
Moisture in the refrigeration circuit can lead to crystal and hydrate formation. For this reason, we
recommendusingalterdrierandasightglasswithamoistureindicator.
