Designation on the name plate Sticker on the terminal box
Y/YY
Y/YY
7.2 Standardmotor,designfordirectorpartialwindingstart
INFO
Amechanicalunloadedstartwithbypasssolenoidvalveis 
notrequired.
7 | Electrical connection
Compressors with this marking are suitable for direct or partial winding start. The motor winding is
subdivided into two parts:
Part winding 1 = 50 % and part winding 2 = 50 %.
This winding division reduces the start-up current needed for a part winding start to approx. 50 % of
that for a direct start.
The motor is wired for direct start (YY) at the factory. For part winding start Y/YY the bridges must
be removed and the motor feed line connected according to the circuit diagram:
ATTENTION Failureto do thisresultsin opposed rotary eldsandresults in
damagetothemotor.Afterthemotorstartsupviapartialwinding
1,partialwinding2mustbeswitchedonafteramaximumdelay
ofonesecond.Failuretocomplycanadverselyaffecttheservice
lifeofthemotor.
400 V
Direktstart YY Teilwicklungsstart Y/YY
1V1 1W11U1
2W12V12U1
L3L2L1 L3L2L1
L3L2L1
1V1 1W11U1
2W12V12U1
Direct start YY
PartwindingstartY/YY
