3 | Product description
3.2 Nameplate (example)
3.3 Typekey (example)
SE 55IP 65
BB12345-A001
HGX66e/2070-4
GEA Bock GmbH
72636 Frickenhausen, Germany
/
HG 66 e
2070 -
4 SX
¹
)
HG - Hermetic Gas-Cooled (suction gas-cooled) for the normal- / air conditioning applications
²
)
X - Ester oil charge (HFC refrigerant, e.g. R134a, R404A/R507, R407C, R407F)
3)
S - More powerful motor, e.g. for air-conditioning applications
Motor variant
3)
Number of poles
Swept volume
e-series
Numbers of cylinders
Size
Oil charge ²
)
Series ¹
)
107,0 A
YY: 335,0 AY: 196,0 A
180,0
217,2
380-420 Y/YY
440-480 Y/YY
1 Type designation 6 Voltage,circuit,frequency
2 Machine number 7 Nominal rotation speed
3 maximum operating current 8 Displacement
4 Starting current (rotor blocked) 9 Voltage,circuit,frequency
Y: Part winding 1 10 Nominal rotation speed
YY: Part windings 1 and 2 11 Displacement
5 ND (LP): Max. admissible operating pressur e 12 Oiltypelledatthefactory
(g) Low pressure side 13 Terminal box protection type
HD (HP): Max. admissible operating Electricalaccessoriescanchange
pressur e (g) High pressure side theIPprotectionclass!
Observethelimitsofapplication
diagrams!
50 Hz
}
60 Hz
}
Fig. 2
