9.3 List of tools
Tool Intended Purpose Material no.
Belt wrench
Removing/mounting the actua-
tor
408-142
Torque wrench ¼“ (2.5-25 Nm) Fitting the clamp connection 408-424
Torque wrench 2-10 Nm Installing the valve 408-486
Torque wrench size 2 (20-120
Nm)
Assembling the valve insert from
individual parts
408-426
Plug tool size 2 (3/ 4")
Assembling the valve insert from
individual parts
408-436
V-ring insertion tool Mount the V-rings 229-109.88
Articulated face spanner ¾”
square adapter 5 mm jour
nal
Removing/mounting the installa-
tion base
408-448
Open-end plug tool
ECO_LAT_DN100
Installing the lantern
221-007481
Open-end plug tool size 2 a/f 17 Assembling the valve insert from
individual parts
408-446
Open-end plug tool size 2 a/f 27 Assembling the valve insert from
individual parts
408-466
Jaw wrench, a/f 10/11 Remove clamp connection 408-033
Jaw wrench, a/f 12/13 Remove clamp connection 408-034
Jaw wrench, a/f 13/17 Removing the switch bar 408-036
Jaw wrench, a/f 24/27 408-040
Assembling device ECO-lantern Installing the lantern 229-000071
Manual emergency actuator
ECO
Remove/mount spring-to-open
valve (NO)
221-310.75
Pick-Set Removing the seals 221-007248
Hose cutter Cutting the pneumatic hoses to
size
407-065
Vice support Removing/mounting V-ring aid 470-001
Socket for wrench ¼" long a/f10 Fitting the clamp connection 408-477
