3 Description
3.1 Design
Fig.5
Design
No. Designation
A Actuator
B T.VIS control top
1 Seal ring
2 Bearing
3 Seal disk
4 Bearing disc
9 Lantern
10 Spacer nut
15 Valve disc C
402 Valve housing
Description
Design
430BAL008331EN_4
18 18.02.2022
