View without hood
Fig.13
Item Designation
1 External initiator
2 Electrical connections
Hint!
For an optimal fit at the air connection, it is necessary to cut the
pneumatic hoses at a right angle with the hose cutter.
6.6 Electrical connection with T.VIS control top
Danger
Live parts
Electrical shock can result in serious personal injury or death.
► Only allow properly qualified staff to carry out work on the electrical
equipment.
► Prior to establishing electrical connections check the maximum
permissible operating voltage.
Explosive gases or dusts
An explosion can result in serious personal injury or death.
► Observe the installation and operating regulations for use in potentially
explosive areas.
Carry out the following steps:
1.
Connect in accordance with the connection diagram and the instructions in
the corresponding operating instructions for control tops T.VIS M-15, A-15 or
T.VIS P-15.
®
Done
Assembly and installation
Electrical connection with T.VIS control top
430BAL008331EN_4
34 18.02.2022
