GEA VARIVENT DN 65 - Tool

Dimensions for Pipes in Inch OD
Inch OD
Outside
diameter
Wall
thickness
Inside
diameter
Outside
diameter acc.
to BS 4825
0.5" 12.7 1.65 9.4 x
0.75" 19.05 1.65 15.75 x
1" 25.4 1.65 22.1 x
1.5" 38.1 1.65 34.8 x
2" 50.8 1.65 47.5 x
2.5" 63.5 1.65 60.2 x
3" 76.2 1.65 72.9 x
4" 101.6 2.11 97.38 x
6" 152.4 2.77 146.86 x
Dimensions for Pipes in Inch IPS
Inch IPS
Outside
diameter
Wall
thickness
Inside
diameter
Outside
diameter
according to
DIN EN ISO
1127
2" 60.3 2 56.3 x
3" 88.9 2.3 84.3 x
4" 114.3 2.3 109.7 x
6" 168.3 2.77 162.76 x
5.6 Tool
List of tools
Tool Material no.
Hose cutter 407-065
Belt wrench 408-142
V-ring insertion tool 229-109.88
Open-ended wrench, ends ground, a/f 17-19 229-119.01
Open-ended wrench, ends ground, a/f 21-23 229-119.05
Open-ended wrench, ends ground, a/f 22-24 229-119.03
Open-ended wrench, a/f 30-32 408-041
Installation mandrel up to DN 50, 2" OD/IPS 229-109.04
Technical data
Tool
430BAL008386EN_3
28 07.02.2022
