13
P1 (2-speed)
P2 (1-speed)
- see note
O3/CP
DIRECT
P3 (1-speed)
- see note
DIRECT
Additional Output
Output 2 (Output 4 on CE)
Output 5
Output 5
Output 4 (Output 2 on CE)
Direct Output 1
P1 (2-speed)
P2 (2-speed)
O3/CP
Output 3
Direct Output 1
Output 6
Output 2 (Output 4 on CE)
Output 5
Output 1
Output 3
Output 4 (Output 2 on CE)
Note: If P2 is used, P1L cannot be used.
Note: If P3 is used, P2L cannot be used.
A3
A2
A1
A5
A1
A4
A5
A26
A3
A2
Connections
AMP output connectors and typical accessories
in.ye-3OP
Option EXT-1R Option EXT-COM
in.ye-5OP
P1
Additional Output
P1 P3P2 P2 O3/CP O3/CP
Outputs illustrated below are typical accessories for AMP connectors� These configurations may change depending on
your control� For more information, please refer to the wiring diagram on the casing cover�
Optional extension communication board for in�temp
support� Can be ordered direcly as an option on in�ye or
separately
Part number:
0610-100006 - extension communication board for
in�temp support
Optional output available� Can be ordered directly as in�ye-
4OP or in�ye-6OP, or separately
Part number: 0610-100005 - extension board for
additional output (0610-100008 European model)
Contact your account manager for more details�
A1
A1
A2
A2
A3
A26
A3 A4
DIRECTDIRECT
A5
A5
