6
Note: The spa pack must be installed at least 4"
(100 mm) above potential flood level. If floor is on ground
level, pack should be raised at least 4" (100 mm).
Important! Read before starting:
Please note that countersunk screws should not be used as they can damage the power box support�
The heat�wav element must be installed on the circuit of the main circulation pump (either the pressure or
the suction side)�
Installation
Warning!
Beware of the application of some products
commonly used against corrosion (such as
WD-40 family products) as they could damage
the pack, due to a negative chemical reaction
between some industrial oils and its plastic
enclosure� Any other materials which may
come in contact with the enclosure must be
carefully evaluated under end use conditions
for compatibility�
4" (100 mm)
Floor installation procedure
The following material is recommended:
4- # 10 screws of appropriate length with round, truss or pan head�
4- washers �5 OD» x �0625» thickness (12 mm OD x 1�5 mm)
Now firmly attach the front feet of the pack to the wooden
floor using 2 more screws backed by 2 washers�
Select the most appropriate location on the floor for
the spa pack and firmly attach the 2 rear feet to the
wooden base using 2 screws backed by 2 washers�
