Gecko in.ye-V3 User Manual

5
10.47”
(266 mm)
17.86”
(454 mm)
19.60”
(498 mm)
12.81”
(325 mm)
18.72”
(475 mm)
4.06”
(103 mm)
4.52”
(115 mm)
10.75”
(273 mm)
2.83”
(72 mm)
Overview
in.ye dimensions
Note: Shown with optional wall mouting brackets (see Installation)�
in.ye overview
55 mm
(2�15 po)
115 mm
(4�56 po)
Front view
Side view
266 mm
(10�47 po)
41 mm
(1�63 po)
Rear view
Bottom view
Main power
entry connection
Optional accessories board
heat�wav heater
in�claw - watertight strain
relief system
Mounting feet
Industry-standard AMP
connectors for outputs
Enough outputs for all
your spa needs
Optional board COM
(RS485)
C1 - Main keypad
connector
a�port (accessories)
k�port (
keypad)
C0 - Communication
connectors
Accessible
bonding lugs
Access to heater
connections
