23
Specifications
in.ye North American electrical specifications
Input rating: 120/240 V nominal (+5/-10 %)
60 Hz, (2 lines required with neutral) 48 A max�
or (in.ye-3 only) : 120 V nominal only (+5/-10 %)
60 Hz, (single line with neutral) 16 A max�
Heat.wav rating:
Voltage : 120 V or 240 V, 60 Hz
Wattage: 5,5 kW at 240 V, 4 kW at 240 V or 1 kW at 120 V
Flow rate: Minimum of 18 GPM (68 LPM) is required
Output Voltage Maximum current Typical Device ye-3* ye-5
Output 1 120 or 240 V 15 FLA/60 LRA (inrush) Pump 2 high speed
•
Output 2 120 or 240 V 15 FLA/60 LRA (inrush) Pump 1 high speed
• •
Output 3 120 or 240 V 15 FLA/60 LRA (inrush) Pump 2 low speed
•
Output 4 120 or 240 V 15 FLA/60 LRA (inrush) Ozonator
• •
Output 5 120 or 240 V 15 FLA/60 LRA (inrush) Pump 1 low speed
• •
Output 6 120 or 240 V 15 FLA/60 LRA (inrush) Pump 3 (4) high speed optional optional
Direct out 1 120 or 240 V 5 A Audio/video
• •
Important:
The maximum current for output 2 and Direct 1 on fuse F1 may not exceed 15 A�
The maximum current for outputs 4, 5 on fuse F2 may not exceed 15 A�
The maximum current for outputs 1 and 3 on fuse F3 may not exceed 20 A�
The maximum current for outputs 6 on fuse F23 may not exceed 15 A�
* This model can be converted to a dedicated 120 V model�
UL/CSA Standards
UL 1563 Sixth Ed� (2012) (rev date 2017)
UL File: E182156
CAN/CSA C22�2 No� 218�1-13 (2013) (Ed� 2 - rev date 2016)
