22
specifications of the selected
socket and patch cord should not
be lower than the rated current on
the nameplate of AC charging
socket assembly.
Charging interface
Charging interface position
The charging interface is located at the
lower left of the right front door. Open the
charging port cover with a key to see the
charging interface.
1. Slow charging port
2. Fast charging port
Charging operation
DC Fast Charging with Charging
Pile
1. Turn the start switch to "OFF" position
and pull up the parking brake.
2. Turn the key clockwise to open the
charging port cover.
3. Open the dust cover A of slow charging
port and the dust cover B of fast
charging port in turn.
4. Unlock the charging plug on the DC
charging pile and insert it into the fast
charging socket of the vehicle body
(please do not press the locking button
of the charging socket) until a "click"
Battery electric power system
