page | 15
3. After a few moments, the screen will go blank and the IP address of both the Sender
and Receiver unit will be displayed in the lower-right corner of the screen.
4. In order to return to the original video channel (without cycling through all 255
channels), access the Web interface for the Receiver unit. Refer to Setting the Video
Channel for more information.
Channel:1
Trying to nd the gateway...
FW: 12-Dec-24 b6e4
Local IP: 169.254.8.168
Remote IP: 169.254.9.227
ID: 82507DA9C07A
Local IP = Receiver unit
Remote IP = Sender unit
Channel:1
Operating the DVI KVM over IP
Basic Operation
