gefran 850 - EVNT.N - Setting the Event Number; FB.O.N - Setting the Function Block Output Number; IN.DG.N - Setting the Digital Input Number; MAST.N - Setting the Master Communication Parameter Number

80209C_MHW_850-1650-1850_02-2020_ENG_pag. 137
4.18.7. EVNT.N - Setting the event number
Acronym Scrolling message Submenu Attributes
EVNT.N OUTPU.1 (o OUTPU.2… OUTPU.4) EVENT NUMBER OUTPU R W
The parameter shows and sets the event number.
The parameter appears if the parameter F.out = P.EVE1, P.EVE2.
Unit of measurement: Number
Options: 1...4
4.18.8. FB.O.N - Setting the Function Block output number
Acronym Scrolling message Submenu Attributes
FB.O.N OUTPU.1 (o OUTPU.2 … OUTPU.4) FUNCTION BLOCK OUTPUT NUMBER OUTPU R W
The parameter shows and sets the number of the Function Block assigned to the output.
The parameter appears if the parameter F.out = LFB.O.
Unit of measurement: Number
Options: 1...32
4.18.9. IN.DG.N - Setting the digital input number
Acronym Scrolling message Submenu Attributes
IN.DG.N OUTPU.1 (o OUTPU.2 … OUTPU.4) DIGITAL INPUT NUMBER OUTPU R W
The parameter shows and sets the number of the digital input assigned to the output.
The parameter appears if the parameter F.out = IN.DIG.
Unit of measurement: Number
Options: 1...3 Model 850 with option 3 digital inputs
1...5 Model 1650 and 1850 with option 5 digital inputs
4.18.10. MAST.N - Setting the Master communication parameter number
Acronym Scrolling message Submenu Attributes
MAST.N OUTPU.1 (o OUTPU.2… OUTPU.4) MASTER PARAMETER NUMBER OUTPU R W
This parameter shows and sets the Master parameter number associated with the output.
This parameter only appears if the F.OUT parameter = MASTER
Unit of measurement: Number
Options: 1...20
4.18.11. SWTCH - Setting the number of switchings for signal
Acronym Scrolling message Submenu Attributes
SWTCH OUTPU.1 (o OUTPU.2 … OUTPU.4) NUMBER OF SWITCHING CYCLES OUTPU R W
The parameter shows and sets the number of switchings (x1000) of the relay, exceeding which the signal is generated
OUTX.SWITCH ALARM where X is the number of output 1 or 2 or 3 or 4 if the output is relay, logic or triac.
The function is disabled if the parameter equals “0”.
Unit of measurement: Number
Options: 0...9999
