4.19. Submenu OUT.AN - Configuring the analog retransmission output
Acronym Scrolling message Password Description
OUT.AN ANALOG
RETRASMISSION
OUTPUT CONFIG
Level 2 Lets you configure the analog output used for retransmission
of analog values.
The submenu appears if the analog retransmission output is
present on the controller.
OU.AN.N
StAt
tYPE
FuNC
LO.SCL
HI.SCL
Selecting the output 141
Defining the state of
the analog output
141
Defining the type of
analog output
142
Selecting the function
assigned to the analog
output
142
Scale minimum 143
Scale maximum 143
Parameter Pag.
