ADL300-EPCv2- User Guide Page 27 of 64
Lift car speed at base frequency. This represents the system speed. It is also used to calculate the
mechanical constant.
Ratio between the speed of the motor and of the pulley.
Pulley diameter setting.
Enables writing of the inertia calculated in the speed regulator (PAR 2240)
Lift car weight setting.
Counterweight setting.
Maximum load weight setting.
Cable weight setting.
Mechanical reducer inertia setting.
Motor inertia setting.
Setting of the method for calculating the unit of measure, based on the speed of the lift car and of the motor
(direct mode) or as a function of the mechanical ratios (mechanical data method).
0 Direct mode
1 Mechanical data
The value of the calculated mechanical constant is displayed.
5.1.2 11042
Gearbox Ratio FLOAT 16/32BIT 45.0 *** *** RW FVS
Pulley Diameter m FLOAT 0.6 *** *** RW FVS
Calc speed reg gain BIT 0 0 1 RW FVS
Car Weight kg FLOAT 0.0 0 10000 RW FVS
Counter Weight kg FLOAT 0.0 0 100000 R/W FVS
Load Weight kg FLOAT 0.0 0 100000 RW FVS
Rope Weight kg FLOAT 0.0 0 100000 RW FVS
5.1.9 11158
GearboxInertia Kgm2 FLOAT 0.0050 0 1000 RW FVS
5.1.10 11160
Motor inertia Kgm2 FLOAT 0.0060 0 1000 RW FVS
Mechanical calc mode ENUM 0 0 1 ERW FVS
5.1.12 12036
Mechanical const m/rev FLOAT R FVS
