____________________ _
ADL300-EPCv2- User Guide Page 28 of 64
The system inertia with half load relayed to the motor is displayed. This value can be entered in the Inertia
parameter in the SPEED REG GAINS menu.
05.02 SPEED
Setting of the value of multispeed 0. This can be selected via digital input, fieldbus, etc.
The value selected is the reference for the lift S ramp.
NB: This speed cannot be changed. It must always be zero
Setting of the value of multispeed 1. The selected value is the reference for the lift S ramp.
The value of this parameter is assumed as forward/reverse speed
Setting of the value of multispeed 2. The selected value is the reference for the lift S ramp.
The value of this parameter is assumed as zero cycle speed.
Setting of the value of multispeed 3. The selected value is the reference for the lift S ramp.
The value of this parameter is assumed as jog speed
Setting of the value of multispeed 4. The selected value is the reference for the lift S ramp.
The value of this parameter is assumed as Self Study speed
Setting of the value of multispeed 5. The selected value is the reference for the lift S ramp.
The value of this parameter is assumed as battery mode speed.
Setting of the value of multispeed 6. This can be selected via digital input, fieldbus, etc.
The value selected is the reference for the lift S ramp.
Setting of the value of multispeed 7. This can be selected via digital input, fieldbus, etc.
The value selected is the reference for the lift S ramp
Setting of the low speed value.
0 Multispeed 0
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.1.13
12050
Inertia Calculated
Kgm2
FLOAT
R
FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.1
11022
Multispeed 0 m/s FLOAT 0.00 0.00 0.00 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.2 11024
Speed fwd / rev m/s FLOAT 1.00 0.00 10000 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.3
11026
Speed zero Cycle m/s FLOAT 0.40 0.00 10000 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.4 11028
Speed jog m/s FLOAT 1.00 0.00 10000 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.5
11030
Speed self-study m/s FLOAT 0.40 0.00 10000 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.6
11032
Speed Battery Mode m/s FLOAT 0.10 0.00 10000 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.7 11034
Multispeed 6 m/s FLOAT 0.00 0.00 10000 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.8
11036
Multispeed 7 m/s FLOAT 0.00 0.00 10000 RW FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.2.9 11038
Speed zero Cyc m/s ENUM 2 0 8 RW FVS
