ADL300-EPCv2- User Guide Page 34 of 64
Self study
Self study command
Dig input 5X
Jog Fwd
Jog forward command
Dig input 7X
Jog Rev
Jog reverse command
Dig input 8X
Realignment
Realignment command
Dig input 9X
Forward
Forward command
Null
Reverse
Reverse command
Null
Stop
Stop command
Null
Maintenance
Maintenance command
Null
Battery Mode
Battery Mode command
Dig input 3X
Battery Run
Battery Run command
Dig input 3X
Floor 0
Floor command bit 0
Dig input 10X
Floor 1
Floor command bit 1
Dig input 11X
Floor 2
Floor command bit 2
Dig input 12X
Floor 3
Floor command bit 3
Null
0 = Up
1 = Down
2 = Autoselect
If the drive is in the emergency condition and cannot find zero, the parameter tells it which direction to move
in.
Setting of the source for the enable command “COMMAND SOURCE LIST”:
1110 Mon ing digitale E
1210 Mon ing digitale 1X
1212 Mon ing digitale 2X
1214 Mon ing digitale 3X
1216 Mon ing digitale 4X
1218 Mon ing digitale 5X
1220 Mon ing digitale 6X
1222 Mon ing digitale 7X
1224 Mon ing digitale 8X
1226 Mon ing digitale 9X
1228 Mon ing digitale 10X
1230 Mon ing digitale 11X
1232 Mon ing digitale 12X
16 Mon com contattore
19 Mon contatt discesa
17 Mon com freno
18 Mon porta aperta
3728 PAD15
6000 Zero
6002 One
20 Lift decom B0
21 Lift decom B1
22 Lift decom B2
23 Lift decom B3
24 Lift decom B4
25 Lift decom B5
26 Lift decom B6
27 Lift decom B7
28 Lift decom B8
29 Lift decom B9
30 Lift decom B10
31 Lift decom B11
32 Lift decom B12
33 Lift decom B13
34 Lift decom B14
35 Lift decom B15
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.5.1
11002
Emergency mode
ENUM
0
RW
FVS
Menu
Par
Description
UM
Type
FB BIT
Def
Min
Max
Acc
Mod
5.5.2
11400
Enable and sel ENUM 1110 RW FVS
