ADL300 - Fast installations and commissioning Pag. 46 of 52
when the regulation board has
just left from production and has
never been configured for any
power. The configuration
adjustment for a given power is
achieved by linking it to a power
board and running a Save
parameters.
This setting determines the
factory voltage and power
supply frequency values.
1 USA (460 / 60 Hz)
The current that the drive can
deliver continuously according
to size, supply voltage and
programmed switching
frequency is displayed
release number of the drive
firmware are displayed.
Identifies the version of the
special firmware installed in the
drive
The drive regulation card serial
number
The drive power card serial
number
number of the encoder firmware
The type of firmware installed in
the encoder
Actual Multispeed Selected
The currently selected speed
Multispeed 0 ÷ Multispeed 7
The speed of the car lift
The lift journey counter is
displayed. The counter
increases each time the Start lift
signal is activated.
Indicates the direction selected
by the drive during the
emergency
1 Forward
2 Reverse
MODE
Indication of the status of
parameter saving.
1 Done
Indication of the status of
execution of motor parameter
self-tuning. The parameter
displays the Requiredmessage
when motor parameter self-
tuning is required. When self-
tuning is complete the
parameter indicates Done.
1 Done
The type of application currently
used by the drive
10 EPC (Direct Approach)
11 DCP3/DCP4
21 DS417 (CANOpen Lift CiA
417)
