3-35
Size 3
H1
H
H2
D
D1
H3
W1
W
D2
E
E1
E2
2-Q
Model
Dimension (mm)
Weight
(kg)
W
W1
H
H1
H2
H3
D
D1
D2
E
E1
E2
Q
BDI50-3037-…
129 118
197.5
177.6
188
154.7
148 143.7
136 102.6
96 48.2 4.5
2,2
(2.4*)
BDI50-3055-…-4
* : With Built-in EMC filter
