gefran BDI50 Series User Manual

4-18
Group 08- Drive & Motor Protection functions
No. Description Range
Factory
Setting
Unit Note
08-00
Trip Prevention Selection
xxxx0: Enable Trip Prevention During
Acceleration
xxxx1: Disable Trip Prevention During
Acceleration
xxx0x: Enable Trip Prevention During
Deceleration
xxx1x: Disable Trip Prevention During
Deceleration
xx0xx: Enable Trip Prevention in Run
Mode
xx1xx: Disable Trip Prevention in Run
Mode
x0xxx: Enable over voltage Prevention
in Run Mode
x1xxx: Disable over voltage Prevention
in Run Mode
00000 -
08-01
Trip Prevention Level
During Acceleration (%)
50 ~ 200 by series
Inverter
Rated
Current
100%
08-02
Trip Prevention Level
During Deceleration (%)
50 ~ 200 by series
08-03
Trip Prevention Level In
Run Mode (%)
50 ~ 200 by series
08-04
Over voltage Prevention
Level in Run Mode
230V: 350.0~390.0
400V: 700.0~780.0
380.0/760.0 VDC *1
08-05
Electronic Motor
Overload Protection
Operation Mode
xxxx0: Disable Electronic Motor
Overload Protection
00001 -
xxxx1: Enable Electronic Motor
Overload Protection
xxx0x: Motor Overload Cold Start
xxx1x: Motor Overload Hot Start
xx0xx: Standard Motor
xx1xx: Invertor Duty Motor ( Force
Vent)
08-06
Operation After
Overload Protection is
Activated
0: Coast-to-Stop After Overload
Protection is Activated
1: Drive Will Not Trip when Overload
Protection is Activated (OL1)
0 -
08-07
Over heat Protection
(cooling fan control)
0: Auto (Depends on temp.)
1: Operate while in RUN mode
2: Always Run
3: Disabled
1 -
08-08
AVR Function
(Auto Voltage
Regulation)
0: AVR function enable
4 -
1: AVR function Disable
2: AVR function disable for stop
3: AVR function disable for
deceleration
4: AVR function disable for stop and
deceleration.
5: When VDC>(360V/740V), AVR
function disable for stop and
deceleration.
08-09
Input phase lost
protection
0: Disabled
1: Enabled
0 -
08-10
PTC Overheat Function
0: Disable 0
1: Decelerate to stop
