Up/Down terminals then keypad can be used to change the frequency by modifying
parameter 05-01.
 03 - 07 =【1】In Up/down frequency mode inverter will ramp up from 0Hz on Run
command
and Ramp down to 0 Hz on stop command.
03- 08
Multifunction terminals S1~S5 scan time
Range
【1~200】 2ms
 Multifunction input terminal On/Off periods will be scanned for the number of cycles according
to the set value in parameter 03-08. If the signal status for On or off period is less than the set
period it will be treated as noise.

Scan period unit is 1ms.
 Use this parameter if unstable input signal is expected, however setting long scan time periods
results in slower response times.
03- 09
s1~s5 Input type selection NO & NC
Range
【
xxxx0
】
:S1 NO
【
xxxx1
】
:S1 NC
【
xxx0x
】
:S2 NO
【
xxx1x
】
:S2 NC
【
xx0xx
】
:S3 NO
【
xx1xx
】
:S3 NC
【
x0xxx
】
:S4 NO
【
x1xxx
】
:S4 NC
【
0xxxx
】
:S5 NO
【
1xxxx
】
:S5 NC
 (NO) Normally open, (NC) Normally closed. Select as required.
 For selecting Normally Open (NO) or Normally Closed(NC) set the relevant digit in
parameter 03-09 to 0 or 1 as required.
 Set Parameter 03-09 first before you use the Parameters 00-02/00-03=1 to set the
inverter run mode to External multifunction inputs.
03-11
Multifunction Output Relay RY1 functions. ( Terminals RB, RA )
Range
【0】:Run
【
1
】
:Fault
【
2
】
:Setting Frequency Reached -------------------------------( refer to 03-14)
【
3
】
:Frequency Reached (3-13±3-14) -------------------------( refer to 03-13/03-14)
【
4
】
:Output Frequency Detection 1 (> 03-13) ----------( refer to 03-13)
【
5
】
:Output Frequency Detection 2 (< 03-13) ----------( refer to 03-13)
【
6
】
:Auto-Restart
【
7
】
:Momentary AC Power Loss----------------------------( refer to 07-00)
【
8
】
:Rapid Stop ( Decelerate to Stop)
【
9
】
:Base Block
【
10
】
:Motor Overload Protection (OL1)
【
11
】
:Drive Overload Protection (OL2)
【
12
】
:Reserved
【
13
】
:Output Current Reached ---------------------------------(refer to 03-15/03-16)
【
14
】
:Brake Control--------------------------------------------(refer to 03-17/03-18)
【15】:PID Feedback Disconnection Detection --------(refer to 10-11/10-13)
03-13
Frequency Detection Level
Range
【
0.00~599.00
】
Hz
03-14
Frequency Detection Width
Range
【
0.00~30.00
】
Hz
