Offset adjustment
31
ofs.
R/W Offset correction for main input
-99,9...99,9
scale points
0,0
0
P. V.
R
Read of engineering value of
process variable (PV)
Read state
scale points
Input lter
28
flt
R/W
Low pass digital filter
on input signal
0,0 .... 20,0 sec
0,1
ADVANCED SETTINGS
Sets a low pass digital lter on the main input, running the average value read in the
specied time interval. If = 0 exclude the average lter on the sampled values.
FUNCTIONAL DIAGRAM
Input
signal
Probe type (tYP).
Scale limits
(Hi.S, Lo.S ).
Offset (oFS).
Low pass
lter
(Flt)
Process
variable (P.V.)
