gefran TPD32-EV-CU series User Manual

—————— Instruction manual ——————
443
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
REG PARAMETERS \ Percent values \ Speed regulator
SpeedP[%]
87 Float 0.00 100.00 10.00 10.00
ü
R/W - -
SpeedI[%]
88 Float 0.00 100.00 1.00 1.00
ü
R/W - -
SpeedPbypass[%]
459 Float 0.00 100.00 10.00 10.00
ü
R/W - -
SpeedIbypass[%]
460 Float 0.00 100.00 1.00 1.00
ü
R/W - -
REG PARAMETERS \ Percent values \ Flux regulator ( Field regulator)
FluxP[%]
91 Float 0.00 100.00 2.00 2.00
ü
R/W - -
FluxI[%]
92 Float 0.00 100.00 1.00 1.00
ü
R/W - -
REG PARAMETERS \ Percent values \ Voltage reg
VoltageP[%]
493 Float 0.00 100.00 30.00 30.00
ü
R/W - -
VoltageI[%]
494 Float 0.00 100.00 40.00 40.00
ü
R/W - -
REG PARAMETERS \ Base values \ Speed regulator
SpeedPbase[A/rpm]
93 Float 000.1 S 0.3x
P93max
P93max
0.3x
P93max
P93max
ü
R/Z - -
SpeedIbase[A/rpm·ms]
94 Float 0.001 S 0.3
P94max
0.3
P94max
ü
R/Z - -
REG PARAMETERS \ Base values \ Flux regulator (Field regulator)
FluxPbase
97 Float 1 32767 3277 3277
ü
R/Z - -
FluxIbase
98 Float 1 32767 3277 3277
ü
R/Z - -
REG PARAMETERS \ Base values \ Voltage reg
VoltagePbase[f%/V]
495 Float 0.0100 S S S
ü
R/Z - -
VoltageIbase[f%/V·ms]
496 Float 0.01 S S S
ü
R/Z - -
REG PARAMETERS \ In use values
SpeedPinuse[%]
99 Float 0.00 100.00 S S
ü
R - -
SpeedIinuse[%]
100 Float 0.00 100.00 S S
ü
R - -
