Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
OPTIONS \ Option 1
AccessibleonlywithoptionalFieldBuscard(seeBuscardusermanual)
OPTIONS \ Option 2
Menu
AccessibleonlywithoptionalAPC300card(seeAPC300cardusermanual)
EnableOPT2
Enabled
Disabled
425 U16 0 1 Disable Disable
ü
R/Z
1
0
- -
OPTIONS \ PID
EnablePIPID
Enabled
Disabled
769 U16 0 1 Disable Disable
ü
R/W
1
0
ID R/W
EnablePDPID
Enabled
Disabled
770 U16 0 1 Disable Disable
ü
R/W
1
0
ID R/W
EnablePI-PDPID
Enabled
Disabled
1258 U16 0 1 Disabled
0
Disabled
0
- R/W
1
0
ID R/W
OPTIONS \ PID \ PID source
PIDsource
786 U16 0 65535 0 0
ü
R/W - -
PIDsourcegain
787 Float -100.000 +100.00 1.000 1.000
ü
R/W - -
Feed-fwdPID
758 I16 -10000 +10000 0 0
ü
R IA R
OPTIONS \ PID \ PID references
PIDerror
759 I16 -10000 +10000 0 0
ü
R - R
PIDfeed-back
763 I16 -10000 +10000 0 0
ü
R/W IA R/W
PIDoffs.Sel
Offset0
Offset1
762 U16 0 1 0 0
ü
R/W
0
1
ID R/W
PIDoffset0
760 I16 -10000 +10000 0 0
ü
R/W IA R/W
PIDoffset1
761 I16 -10000 +10000 0 0
ü
R/W - -
PIDacctime
1046 Float 0.0 900.0 0.0 0.0
ü
R/W - -
PIDdectime
1047 Float 0.0 900.0 0.0 0.0
ü
R/W - -
PIDclamp
757 I16 -10000 +10000 10000 10000
ü
R/W - -
OPTIONS \ PID \ PI controls
PIPgainPID
765 Float 0.00 100.00 10.00 10.00
ü
R/W - -
PIIgainPID
764 Float 0.00 100.00 10.00 10.00
ü
R/W - -
PIsteadythr
695 I16 0 10000 0 0
ü
R/W - -
PIsteadydelay
731 U16 0 60000 0 0
ü
R/W - -
PinitgainPID
793 Float 0.00 100.00 10.00 10.00
ü
R/W - -
IinitgainPID
734 Float 0.00 100.00 10.00 10.00
ü
R/W - -
PIcentralvsel
779 U16 0 3 1 1
ü
R/W ID R/W
PIcentralv1
776 Float PIbot-
tomlim
PItop
lim
1.00 1.00
ü
R/W - -
PIcentralv2
777 Float PIbot-
tomlim
PItop
Lim
1.00 1.00
ü
R/W - -
PIcentralv3
778 Float PIbot-
tomlim
PItop
Lim
1.00 1.00
ü
R/W IA -
PItoplim
784 Float PIbot-
tomlim
10.00 10.00 10.00
ü
R/W - -
PIbottomlim
785 Float -10.00 PItoplim 0.0 0.0
ü
R/W - -
PIintegrfreeze
OFF
ON
783 U16 0 1 0 0
ü
R/W
0
1
ID R/W
PIoutputPID
771 I16 0 1000x
PItop
limit
1000 1000
ü
R - R
RealFFPID
418 I16 -10000 +10000 0 0
ü
R/W - R
OPTIONS \ PID \ PD control
PDPgain1PID[%]
768 Float 0.00 100.00 10.00 10.00
ü
R/W - -
PDDgain1PID[%]
766 Float 0.00 100.00 1.00 1.00
ü
R/W - -
