gefran TPD32-EV-CU series User Manual

—————— TPD32-EV ——————
464
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
PDPgain2PID[%]
788 Float 0.00 100.00 10.00 10.00
ü
R/W - -
PDDgain2PID[%]
789 Float 0.00 100.00 1.00 1.00
ü
R/W - -
PDPgain3PID[%]
790 Float 0.00 100.00 10.00 10.00
ü
R/W - -
PDDgain3PID[%]
791 Float 0.00 100.00 1.00 1.00
ü
R/W - -
PDDlterPID[ms]
767 U16 0 1000 0 0
ü
R/W - -
PDoutputPID
421 I16 -10000 +10000 0 0
ü
R - -
PIDoutsignPID
Positive
Bipolar
772 U16 0 1 1 1
ü
R/W
0
1
- -
PIDoutput
774 I16 -10000 +10000 0 0
ü
R QA R
OPTIONS \ PID \ PID target
PIDtarget
782 U16 0 65535 0 0
ü
R/W - -
PIDoutscale
773 Float -100.000 -100.000 1.000 1.000
ü
R/W - -
OPTIONS \ PID \ Diameter calc
Diametercalc
Enabled
Disabled
794 U16 0 1 0 0
ü
Z/R
1
0
ID R/W
Positioningspd[rpm]
795 I16 -100 +100 0 0
ü
R/W - -
Maxdeviation
796 I16 0 +10000 8000 8000
ü
R/W - -
Gearboxratio
797 Float 0.001 1.000 1.000 1.000
ü
R/W - -
Dancerconstant[mm]
798 U16 1 10000 1 1
ü
R/W - -
Minimumdiameter[cm]
799 U16 1 2000 1 1
ü
R/W - -
OPTIONS \ PID
PIcentralvs0
780 U16 0 1 1 1 - R/W ID R/W
PIcentralvs1
781 U16 0 1 0 0 - R/W ID R/W
Diametercalcst
800 U16 0 1 0 0 - R QD R
OPTIONS \ TORQUE WINDER
TorquewinderEn
Enabled
Disabled
1209 U16 0 1 Disabled
0
Disabled
0
ü
R/W
1
0
ID R/W
OPTIONS \ TORQUE WINDER \ Diam Calculatio
Rolldiameter[m]
1154 Float 0.000 32.000
ü
R QA -
Linespeed[%]
1160 Float 0.00 200.00
ü
R - -
Reflinespeed[%]
1286 Float 0.00 200.00
ü
R - -
DiamcalcDis
ON
OFF
1161 U16 0 1 ON
(1)
ON
(1)
ü
R/W
1
0
ID R/W
Diaminc/decEn
Enabled
Disabled
1205 U16 0 1 Enabled
(0)
Enabled
(0)
ü
R/W
1
0
ID R/W
Wind/unwind
Unwinder
Winder
1187 U16 0 1 Winder
(0)
Winder
(0)
ü
R/W
1
0
ID R/W
Minimumdiameter[mm]
799 U16 1 2000 100 100
ü
R/Z - -
Maximumdiameter[m]
1153 Float 0.000 32.000 1.000 1.000
ü
R/Z - -
Linespdsource
1204 U16 0 65535 0 0
ü
R/Z - -
Refspdsource
1284 U16 0 65535 0 0
ü
R/Z - -
Linespeedgain
1156 I16 0 32767 0 0
ü
R/W - -
Refspeedgain
1285 I16 0 32767 0 0
ü
R/W - -
Baseomega[rpm]
1163 U16 0 8191 1500 1500
ü
R/W - -
Refspeedthr[%]
1155 Float 0 150.00 5 5
ü
R/W - -
Diamlter[ms]
1162 U16 0 5000 100 100
ü
R/W - -
Diaminitlter[ms]
1206 U16 0 5000 100 100
ü
R/W - -
Diamstdydelay[ms]
1207 U16 0 60000 0 0
ü
R/W - -
