Performance description of the power generator
Page 19
3.7. Technical data
Type 2801
Speed rpm 3000
Frequency Hz 50
Voltage V 230
Electrical power VA 2500
Current A 11
Power factor cos phi 1.0
Drive motor Biggs & Stratton 950 Series™
Single-cylinder four-stroke engine, OHV
valve-controlled, forced-air cooled
Capacity cm³ 208
Maximum performance hp 5.4 at 3000 rpm
Engine oil lling quantity ltr 0.6
Tank contents, fuel ltr 13
Dimensions LxWxH mm 670x445x485
Weight kg 48,0 kg
Sound power level db(A) 96
Sound pressure level db(A) 68
The specied power of the generator is applicable at the temperature and altitude indicated on the
rating plate.
