Start-up ZA08
Setting the lower mechanical stop
The setting of the lower mechanical stop must take place without
load and the reciprocator must be disconnected from mains!
Procedure:
1. Switch off the electric power
2. Release the brake switch manually
3. Let the Z carriage sink down until the powder gun holder is
approximately 50 mm above edge of the gun slot
4. Remove the boarding/side panels
5. Loosen the screws and move the lower stop plate up to the Z
carriage
6. Tighten the screws
Tightening torque: 55 Nm
7. Refit the boarding/side panels
Setting the upper mechanical stop
The setting of the upper mechanical stop must take place without
load and the reciprocator must be disconnected from mains!
In order to set the upper mechanical stop, the stop position hast to be
measured – for this reason, consider the maximum height of the booth
gun slots!
An incorrect (too high) set stroke limit will lead to damage to the
vertical axis and/or the booth!
► Before connecting or switching on the reciprocator, read carefully
these operating instructions!
► See the user manual of the axis control unit!
Procedure:
1. Remove the boarding/side panels
2. Loosen the screws and move the upper stop plate up to the
measured position
3. Tighten the screws
Tightening torque: 55 Nm
4. Refit the boarding/side panels
After the adjustment of the mechanical stops, check the system
parameter for the upper stop on the axis control unit!
The value must not be larger than the maximum stroke possible
between the stops!
