Gema ZA08 - Toothed Wheel Components

Rev. 01 11/22
56
•
Spare parts list ZA08
Toothed wheel
1
Eye bolt – M16
264 415
2
Guide plate
386 588
3
Hexagon shakeproof nut – M8
244 449
4
Hexagon ribbed nut – M10
234 656
5
Counter profile – 40/20x115 mm
386 774
6
Toothed wheel
386 600
7
Toothed belt
103 730#*
ZA08-13 – L=4215 mm
ZA08-18 – L=5215 mm
ZA08-23 – L=6215 mm
ZA08-28 – L=7215 mm
8
Tensioning screw
386 596
9
Hexagon shakeproof screw – M6x12 mm
244 406
10
Locking plate
386 634
11
Hexagon shakeproof screw – M8x20 mm
244 422
12
Toothed drive wheel spindle
386 766
13
Spacer ring – Ø 31.9/28x11 mm
386 618
14
Deep groove ball bearing – Ø 15/32x9 mm
241 709
15
Snap ring – A-15
233 617
16
Snap ring – I-32
245 780
17
Eye bolt – M10x60 mm
264 202
18
Rubber buffer – Ø 35x40 mm, M8
211 664
19
Stop plate
386 782
20
Ribbed washer – M10
237 981
21
Hexagon screw – M10x180 mm
201 855
* Please indicate length
# Wearing part
