Gemalto Cinterion ALAS5 User Manual

Cinterion
®
ALAS5 Hardware Interface Overview
1.2 Key Features at a Glance
15
 ALAS5_HIO_v00.030a 2019-04-01
Confidential / Preliminary
Page 14 of 50
CA_41A-41A 0, 1 W
Inter-band (two bands)
CA_1A-5A 0, 1 W
CA_1A-8A 0, 1, 2 W
CA_1A-18A 0, 1 W
CA_1A-19A 0 W
CA_1A-20A 0 W
CA_1A-26A 0, 1 W
CA_1A-28A 0, 1 W
CA_2A-13A 0, 1 AM
CA_3A-5A 0, 1, 2, 3,4 W
CA_3A-8A 0, 1, 2, 3 W
CA_3A-19A 0 W
CA_3A-20A 0, 1 W
CA_3A-26A 0, 1 W
CA_3A-28A 0, 1 W
CA_4A-13A 0, 1 AM
CA_5A-7A 0, 1 AM, W
CA_5A-40A 0, 1 W
CA_7A-8A 0, 1, 2 W
CA_7A-20A 0, 1 W
CA_7A-28A 0, 1 AM, W
CA_7B-28A 0 AM, W
CA_8A-40A 0, 1 W
CA_8A-41A 0, 1 W
CA_13A-66A 0 AM
CA_13A-66B 0 AM
CA_20A-38A 0 W
CA_20A-40A 0 W
CA_26A-41A 0 W
CA_28A-40A 0 W
CA_28A-41A 0, 1 W
Table 2: Supported CA configurations
Downlink CA Bandwidth
combination set
Product variant
(ALAS5-...)
