Cinterion
®
ALAS5 Hardware Interface Overview
2.2 GSM/UMTS/L
TE
Antenna Interface
32
ALAS5_HIO_v00.030a
2019-04-01
Confidential / Preliminary
Page 26 of 50
Micro-Stripline
This section gives two line arrangement
examples for micro-stripline.
Figure 9:
Micro-
Stripline line arrangement sample
s
25
27
