Cinterion
®
ALAS5 Hardware Interface Overview
1.2 Key Features at a Glance
15
ALAS5_HIO_v00.030a 2019-04-01
Confidential / Preliminary
Page 13 of 50
1.2.2 Supported CA Configurations
The following table lists the supported CA configurations (aka supported band combinations)
for each of the ALAS5 product variants mentioned in Section 1.1.
Bd.29 (700MHz)
<supplementary downlink>
x
Bd.30 (2300MHZ)
<supplementary downlink>
x
Bd.32 (1500MHz)
<supplementary downlink>
x
Bd.66 (1700MHz)
x
LTE-TDD
Bd.34 (2000MHz) x
Bd.38 (2600MHz)
x
Bd.39 (1900MHz)
x
Bd.40 (2300MHz)
x
Bd.41 (2600MHz)
1
x
1. Note: Out of the 3GPP specified frequency range for LTE Band 41,
only that part which is used in China and Japan (2545MHz to
2655MHz) is supported by ALAS5.
Table 2: Supported CA configurations
Downlink CA Bandwidth
combination set
Product variant
(ALAS5-...)
Intra-band continuous
CA_1C 0, 1 W
CA_3C 0 W
CA_5B 0, 1 AM, W
CA_7B 0 AM, W
CA_7C 0, 1, 2 AM, W
CA_8B 0 W
CA_38C 0 W
CA_39C 0 W
CA_40C 0, 1 W
CA_41C 0, 1, 2, 3 W
Intra-band non-continuous
CA_3A-3A 0, 1, 2 W
CA_7A-7A 0, 1, 2, 3 AM, W
CA_40A-40A 0, 1 W
Table 1: Supported frequency bands for each product variant
Band ALAS5-W ALAS5-AM
